Description
Specifications
| Processor | Industrial-grade processor |
| Operating System | Embedded LINUX |
| IP Camera Input | 16 Channel |
| User Interface | Web, Local GUI |
| AI by Recorder | SMD |
| AI by Camera | Perimeter protection, SMD |
| Perimeter Performance | All channels (4 targets) |
| Video Output | HDMI: 3840×2160, 1920×1080 VGA: 1920×1080, 1280×1024, 1280×720 |
| Video Compression | H.265, H.264, H.264+, MJPEG |
| Encode Strategy | Smart |
| Decoding Capability | AI disabled: 1ch@12MP / 3ch@8MP / 5ch@5MP / 6ch@4MP / 8ch@1080P AI enabled: 1ch@8MP / 4ch@1080P |
| Video Resolution | 12MP, 8MP, 5MP, 4MP, 3MP, 2MP, 720P, D1, CIF |
| Video Display Split | 1/4/8/9/16 |
| SMD Plus by NVR | 4-channel filtering for human & vehicle |
| SMD Plus by Camera | All channels (8 targets) |
| Network Bandwidth | Incoming 160 Mbps, Recording 72 Mbps, Outgoing 72 Mbps |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, P2P, ONVIF |
| Abnormal Alarm | Error, Disk full, Disk error, Network disconnect, IP conflict |
| Intelligent Alarm | Perimeter protection, SMD+ |
| General Alarm | Motion detection, Video loss, Alarm input |
| Alarm Linkage | Recording, Snapshot, Buzzer, Email |
| Audio Input | 1 channel RCA |
| Audio Output | 1 channel RCA |
| Audio Compression | G.711a, G.711u, PCM, AAC |
| Hard Disk | 2 SATA ports, up to 20TB |
| Multi-channel Playback | Up to 16 channels |
| Record Mode | General, Motion, Alarm |
| Playback Mode | Instant, General, Event |
| Interface Ports | 2 USB (Front & Rear) |
| Backup Method | USB & Network |
| Smart Phone | iOS, Android |
| Ethernet | 1 × RJ45 (10/100/1000 Mbps) |
| Browser | Chrome, Edge, Firefox |
| Power Supply | DC 12V, 4A |
| Power Consumption | <10W (Without HDD) |
| Operating Temperature | -10°C to 45°C |
| Operating Humidity | 10%–90% RH |
| Storage Temperature | -20°C to 60°C |
| Dimensions | 375 × 292 × 53 mm |
| Weight | 1400 g (Without HDD) |
