Description
| Feature | Specification |
|---|---|
| AC Input Voltage | 150~265VAC |
| DC Output voltage | 12VDC |
| Rated Power | 60W |
| Ripple & Noise (max.) | 140mV(max) |
| Voltage Adj. Range | NA |
| Device | Primary-Side Regulation |
| Device (frequency) | 132KHz |
| VDS Voltage | 616V(max) |
| Line Regulations | ±1% |
| Load Regulations | ±5% |
| SCP | Output short-circuit protection |
| OPP, OCP | Output overload/over-current protection |
| OVP | Output overvoltage protection, auto-restart or latching |
| Line UV | Line brown-in/out protection |
| OV | Line overvoltage shutdown extends line surge withstand |
| OTP | Accurate thermal shutdown, hysteretic or latching |
| Efficiency (Typ.) | 83% |
| Frequency Range | 47~63HZ |
| Storage Temperature | 0~50°C |
