Description
Specifications
| SECURITY | |
|---|---|
| Access Control | Source/Destination IP-based Access Control |
| Filtering | • WEB Group Filtering • URL Filtering • Web Security |
| ARP Inspection | • Send/ARP request • ARP scanning • IP/MAC binding |
| Attack Defense | • TCP/UDP/ICMP Flood Defense • Block DoS/DDoS Attack • Blocking from WAN |
| HARDWARE FEATURES | |
| Standard & Protocol | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Interface | • 1 Gigabit WAN Port • 3 Gigabit LAN Ports • USB Port |
| Network Media | 10/100/1000Base-T Ethernet |
| Fan Quantity | Fanless |
| Button | Reset Button |
| Power Supply | External 12V/1A Adapter |
| Flash | 16MB |
| DRAM | 256MB DDR |
| LED | Power, WAN, LAN |
| Dimensions | Approx. 158 × 101 × 25 mm |
| Protection | 4KV Surge Protection |
| Mounting | Desktop |
| PERFORMANCE | |
| Concurrent Sessions | 50,000 |
| New Sessions/sec | 2,000 |
| Firewall Throughput | Up to 1 Gbps |
| VPN Throughput | Up to 300 Mbps |
| BASIC FUNCTIONS | |
| WAN Connection Type | Static IP, Dynamic IP, PPPoE |
| DHCP | DHCP Server, DHCP Client |
| QoS | Bandwidth Control |
| VLAN | 802.1Q VLAN |
| ADVANCED FEATURES | |
| Routing | Static Routing |
| Load Balance | Multi-WAN Load Balance |
| NAT | One-to-One NAT, Port Forwarding |
| VPN | |
| Protocols | IPSec, PPTP, L2TP |
| VPN Users | Supports multiple VPN tunnels |
| MANAGEMENT FEATURES | |
| Management | Web UI, Remote Management |
| Monitoring | Traffic Statistics |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Operating Temperature | 0°C ~ 40°C |
| Storage Temperature | -40°C ~ 70°C |
| Humidity | 10% ~ 90% (non-condensing) |
