| Image Sensor | 1/2.9″ 4MP PS CMOS Image Sensor (0.8758 cm) |
|---|
| Effective Pixels | 2688 × 1520 |
|---|
| Minimum Illumination | 0.03 Lux@F2.0 (Color), 0.003 Lux@F2.0 (B/W), 0 Lux (IR On) |
|---|
| Angle Adjustment | Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° |
|---|
| Shutter Speed | Auto/Manual 1/3 s – 1/100000 s |
|---|
| White Balance | Auto, Natural, Street Lamp, Outdoor, Manual, Regional custom |
|---|
| RAM | 128 MB |
|---|
| ROM | 128 MB |
|---|
| DORI Distance | Lens 3.6mm: 85.4 m (Detect), 34.2 m (Observe), 17.1 m (Recognize), 8.5 m (Identify) |
|---|
| Gain Control (AGC) | Auto/Manual |
|---|
| Lens Type | Fixed focal |
|---|
| Max Aperture | F1.6 |
|---|
| Day/Night | Auto(ICR)/Color/B/W |
|---|
| Lens Mount | M12 |
|---|
| Close Focus Distance | 1.7 m |
|---|
| Lens | 3.6mm fixed lens |
|---|
| S/N Ratio | >56 dB |
|---|
| Angle of View | H: 78°, V: 43°, D: 92° |
|---|
| Back Light Compensation | BLC / HLC / DWDR |
|---|
| IR Number | 1 IR LED + Warm Light |
|---|
| IR | IR Range of 30 Mtr. |
|---|
| Warm Light | Warm Light Range of 30 Mtr. |
|---|
| Smart IR | Support |
|---|
| Smart Illumination | Support |
|---|
| Stream Capability | Triple stream |
|---|
| Frame Rate | Main stream: 4MP (2688×1520) |
|---|
| Video Compression | H.265, H.264, H.264B, MJPEG (sub stream) |
|---|
| Resolution | 4MP, 3MP, 1080P, 720P, D1 |
|---|
| Smart Search | Work with Smart NVR for intelligent search |
|---|
| Noise Reduction | 3D NR |
|---|
| Motion Detection | Off/On (4 areas, rectangular) |
|---|
| Video Format | PAL/NTSC |
|---|
| Privacy Mask | 4 areas |
|---|
| ROI | Support (4 areas) |
|---|
| OSD | Camera title, Date & Time |
|---|
| Audio Compression | G.711A, G.711U, PCM, G.726, AAC |
|---|
| Protocol | HTTP, HTTPS, RTSP, TCP/IP, UDP, ONVIF, SNMP, FTP |
|---|
| SDK and API | Support |
|---|
| Ethernet | RJ-45 (10/100 Base-T) |
|---|
| Cyber Security | AES Encryption, HTTPS, Password protection |
|---|
| IVS (Intelligent Motion Detection) | Human & Vehicle detection |
|---|
| Mirror Function | Support |
|---|
| Audio | Built-in Mic |
|---|
| IR Control | Auto, Manual |
|---|
| Iris Control | Fixed |
|---|
| Alarm Event | Network disconnection, IP conflict, Motion detection, Video tampering, Audio detection |
|---|
| Image Rotation | 0° / 90° / 180° / 270° |
|---|
| Bit Rate Control | CBR/VBR |
|---|
| Bit Rate | H.265: 3 kbps–6144 kbps |
|---|
| User/Host | 6 users |
|---|
| Browser | IE, Chrome, Firefox |
|---|
| Weatherproof Standard | IP67 |
|---|
| Certificates | CE, FCC, RoHS |
|---|
| Power Source | 12V DC / PoE |
|---|
| Power Consumption | Max 4.7W |
|---|
| Operating Temperature | -40°C to +60°C |
|---|
| Operating Humidity | ≤95% RH |
|---|
| Storage Temperature | -40°C to +60°C |
|---|
| Storage Humidity | ≤95% RH |
|---|
| Dimensions | 85.5 mm × 109 mm |
|---|
| Casing | Metal + Plastic |
|---|
| Weight | 250 g |
|---|
