| Image Sensor | 1/2.8″ 2MP PS CMOS Image Sensor (0.907 cm) |
|---|---|
| Effective Pixels | 1920 × 1080 |
| Minimum Illumination | 0.01 Lux@F2.0 (Color), 0 Lux (IR On) |
| Angle Adjustment | Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° |
| Shutter Speed | Auto/Manual 1/3s – 1/100000s |
| White Balance | Auto, Natural, Street Lamp, Outdoor, Manual, Regional |
| RAM | 128 MB |
| ROM | 128 MB |
| DORI Distance | 52.4m (Detect), 21.0m (Observe), 10.5m (Recognize), 5.2m (Identify) |
| Gain Control (AGC) | Auto / Manual |
| Lens Type | Fixed |
| Max Aperture | F2.0 |
| Lens Mount | M12 |
| Close Focus Distance | 0.9 m |
| Lens | 3.6mm (2.8mm optional) |
| Video Compression | H.265, H.264, H.264B, MJPEG (sub stream) |
| S/N Ratio | >56dB |
| IR Number | 1 IR LED |
| IR Range | 30m |
| IR Control | Auto / Manual |
| Smart IR | Supported |
| Day/Night | Auto(ICR)/Color/B/W |
| WDR | BLC / HLC / DWDR |
| Stream Capability | Triple Stream |
| Frame Rate | Main stream: 1920×1080@30fps |
| Video Format | PAL/NTSC |
| Privacy Mask | 4 areas |
| Resolution | 2MP, 1.3MP, 720P, D1 |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| ROI | Supported |
| OSD | Camera title, Date & Time |
| Audio | Built-in Mic |
| Audio Compression | G.711A, G.711U, PCM, G.726, AAC |
| Bit Rate | H.265: 3–6144 kbps |
| Bit Rate Control | CBR / VBR |
| Human Detection | Supported |
| Protocol | HTTP, HTTPS, RTSP, TCP/IP, UDP, ONVIF, SNMP, FTP |
| SDK/API | Supported |
| Ethernet | RJ-45 (10/100 Base-T) |
| Alarm Event | Network disconnection, IP conflict, Motion detection, Video tampering |
| Cyber Security | AES Encryption, HTTPS, Password protection |
| Mirror Function | Supported |
| User/Host | 6 users |
| Image Rotation | 0° / 90° / 180° / 270° |
| Browser | IE, Chrome, Firefox |
| Weatherproof | IP67 |
| Power Supply | 12V DC / PoE |
| Power Consumption | Max 4.4W |
| Operating Temperature | -40°C to +60°C |
| Operating Humidity | ≤95% |
| Storage Temperature | -40°C to +60°C |
| Storage Humidity | ≤95% |
| Dimensions | 162.6 × 70 × 70 mm |
| Casing | Metal + Plastic |
| Weight | 220g |
